均化设备

生料分配器

丁宝勤 13906276368(技术) 周龙泰 13606279370(商务)

电话:0513-88400999 传真:0513-88400998 邮箱:jszk@vip.163.com



生料分配器是水泥工业气动化装置,主要用在分配干燥粉状物料,它适用于输送设备的中间分料及库顶物料分配。可根据工艺要求生产二嘴、六嘴、八嘴,出料嘴斜度可按工艺在6°至 14°范围内选择。适用于大、中、小型水泥厂分配水泥、生料之用。
Raw material distributor is a pneumatic device in cement industry. Mainly apply in distributing dry and powder material and suit to convey middle material and top silo material. Manufacture 2 spouts, 6 spouts and 8 spouts according to workmanship request. The slope of outlet is selected from 6 degree to 14 degree according to workmanship. It is widely used in small, middle and big cement factory to distribute cement and raw material.


技术参数表

型号(mml Type(mm)

生料通过能力(t/hl Raw material capacity (t/h )

风压(mmHzO}

Wind pressure (mmH20)

风量(m3/min) Volume(m3/min)

Φ800

6嘴(6 spouts)

<120

700

2

8嘴(8 spouts)

<140

2.5

Φ1000

6嘴(6 spouts)

75 ~ 130

700

3

8嘴(8 spouts)

90〜150

4

Φ1200

6嘴(6 spouts)

130-150

700

4.5

8嘴(8 spouts)

150-180

5

Φ1600

6嘴(6 spouts)

>150

700

7

8嘴(8 spouts)

>180

8


分配器外形图



生料分配器
