PF反击式破碎机

       本系列产品具有二级反击板、三级反击板,能处理边长100-180mm以下物料,使用于破碎中硬物料,其抗压强度可达350兆帕,出料粒度比较小,物料颗粒度良好,呈立方体颗粒。转子部件精心制作、转子动,静平衡好、机器运行平稳、噪音小。
The series of products has secondary and tertiary impact plates. It can handle the materials with a side length less than 100-180 mm. It is used for crushing materials with a medium hardness. The compressive strength reaches 350MPa,and the particle size is relatively small and good. showing a cubic shape. The rotor components are elaborate. The rotor has a good dynamic and static balance. The machine is in a stable operation with small noise.

产品特点Product features
■独特的设计、破碎效果好
■优秀的转子结构设计
■反击架可调方便灵活
■选用最耐用的部件材料
■良好的机架开启结构设计
■高质量的焊接工艺技术
Unique design, good crushing effect
Excellent desing of the rotor structure
The adjustment of impact rack is convenient and flexible
Select the most durable materials
Good design of frame opening structure
High-quality welding technology


技术参数表|Technical Date


型号

原型号

转子规格

(mm )

进料口尺寸

(mm )

最大进料

(mm )

生产能力

(t/h)

功率

(kw)

重量(kg )

PF1010II

PF-1010VI

Ф1000×1050

400×1080

350

50-80

55

12127

PF1210II

PF-1210VI

Ф1280×1050

400×1080

350

70-120

110

12500

PF1214II

PF-1214VI

Ф1280×1400

400×1430

350

95-145

132

15300

PF1315II

PF-1315VI

Ф1320×1500

800×1530

500

120-200

185

18920

PF1010III

PF-A-1010V

Ф1000×1050

400×1080

350

50-80

55

12820

PF1210III

PF-1210V

Ф1280×1050

400×1080

350

70-120

110

14100

PF1214III

PF-1214V

Ф1280×1400

400×1430

350

95-145

132

16800

PF1315III

PF-1315V

Ф1320×1500

800×1530

300

100-180

185

20975

PF1320 III

PF-1320V

Ф1320×2000

800×2030

400

280-320

280

29700

PF1420 III

PF-1420

Ф1400×2000

1250×2030

600

250-350

355

40000

PF1515III

PF-1515

Ф1500×1500

980×1610

500

220-280

280-315

30500

PF1620 III

PF-1620

Ф1600×2000

1600×2080

600-800

350-450

560

47500
